When your VMware vCenter Server Appliance (VCSA) root password expires, it can disrupt your entire virtual infrastructure management. This comprehensive guide walks you through the proven methods to reset VMware vCenter root password after expiration, ensuring minimal downtime for your environment.
Understanding vCenter Root Password Expiration
VMware vCenter Server Appliance enforces password expiration policies by default. The root account password typically expires after 90 days, which can lock administrators out of critical system functions. When this happens, you’ll need to access the appliance through alternative methods to reset the credentials.
Common Symptoms of Expired Root Password
Before attempting to reset VMware vCenter root password after expiration, verify you’re experiencing these issues:
- Unable to SSH into the VCSA
- Login failures at the direct console interface
- Error message: “Your password has expired”
- Management interface accessibility problems
Prerequisites for Password Reset
Before proceeding with the password reset procedure, ensure you have:
- Direct console access to the vCenter Server Appliance (via VMware ESXi host client or vSphere Client)
- Physical or remote console access through your hypervisor
- Administrator credentials for the underlying ESXi host
- Current backup of vCenter configuration (recommended)
Click here to download VMware vSphere 8
Method 1: Reset Password via GRUB Boot Menu (VCSA 6.7 and Later)
This method is the most reliable approach to reset VMware vCenter root password after expiration for modern VCSA versions.
Step-by-Step Instructions
Step 1: Access the VCSA Console
Open the virtual machine console through your ESXi host client or vSphere web interface. You’ll need direct access to the boot screen.
Step 2: Reboot into GRUB Menu
Restart the VCSA appliance and press the ‘e’ key when the Photon OS boot menu appears. This must be done quickly during the boot sequence.
Step 3: Modify Boot Parameters
Locate the line beginning with “linux” that contains the kernel boot parameters. Navigate to the end of this line and append:
rw init=/bin/bash
Press F10 or Ctrl+X to boot with these modified parameters.
Step 4: Remount Filesystem
Once the bash prompt appears, remount the root filesystem with read-write permissions:
mount -o remount,rw /
Step 5: Reset the Root Password
Execute the passwd command to reset VMware vCenter root password after expiration:
passwd root
Enter your new password twice when prompted. Ensure it meets VMware’s complexity requirements: minimum 8 characters, including uppercase, lowercase, numbers, and special characters.
Step 6: Update Password Expiration
To prevent immediate re-expiration, modify the password aging policy:
chage -M 99999 root
This sets the maximum password age to approximately 274 years.
Step 7: Reboot Normally
Complete the process by rebooting the appliance:
reboot -f
Method 2: Using Appliance Shell for VCSA 6.5
For vCenter Server Appliance 6.5, the process differs slightly from newer versions.
Accessing Single User Mode
Restart the VCSA and press ‘e’ at the boot menu. Find the kernel boot line and replace:
quiet
with:
rw init=/bin/bash
After booting, mount the filesystem and follow steps 4-7 from Method 1.
Method 3: Password Reset via vCenter Server Management Interface
If you retain access to the vCenter Server Appliance Management Interface (VAMI) on port 5480, you can reset VMware vCenter root password after expiration through the GUI.
VAMI Access Steps
Navigate to https://vcenter-fqdn:5480 and login with an administrator account that hasn’t expired. Under the “Administration” section, select “Users” and modify the root account password directly.
This method requires that at least one administrator account remains valid and that the management interface is accessible.
Post-Reset Configuration
After successfully resetting the password, implement these best practices:
Configure Password Policies
Access the VCSA through SSH and review password expiration settings:
chage -l root
Adjust policies according to your organization’s security requirements while ensuring you won’t face unexpected lockouts.
Update Password Management Documentation
Document the new password in your organization’s secure password management system. Update runbooks and disaster recovery procedures to reflect current credentials.
Enable Email Notifications
Configure vCenter to send email alerts before password expiration:
- Log into vCenter Server Appliance Management Interface
- Navigate to Administration > Email Settings
- Configure SMTP server and notification preferences
- Test email delivery for password expiration warnings
Troubleshooting Common Issues
Unable to Access GRUB Menu
If you cannot interrupt the boot process quickly enough, adjust the GRUB timeout. Once you successfully boot, edit /boot/grub2/grub.cfg and increase the timeout value.
Filesystem Remains Read-Only
If the remount command fails, verify the disk integrity:
Troubleshooting Common Issues
Unable to Access GRUB Menu
If you cannot interrupt the boot process quickly enough, adjust the GRUB timeout. Once you successfully boot, edit /boot/grub2/grub.cfg and increase the timeout value.
Filesystem Remains Read-Only
If the remount command fails, verify the disk integrity:
This checks and repairs the root filesystem before attempting the remount.
Password Complexity Errors
VMware enforces strict password complexity requirements. Ensure your new password includes:
- Minimum 8 characters
- At least one uppercase letter
- At least one lowercase letter
- At least one number
- At least one special character
- No dictionary words or common patterns
Prevention Strategies
Implement Proactive Monitoring
Set up monitoring alerts 30 days before password expiration using vCenter alarms or third-party monitoring tools. This provides adequate time for planned password changes.
Use Configuration Management
Deploy infrastructure-as-code practices that automatically track and update password expiration dates. Tools like Ansible, PowerCLI, or Terraform can help manage credential lifecycles.
Regular Password Rotation Schedule
Establish a quarterly password rotation schedule for critical infrastructure accounts. This prevents emergency situations caused by unexpected expirations.
Security Considerations
When performing password resets, maintain security best practices:
- Always create backups before making system-level changes
- Document all password reset activities in change management systems
- Use strong, unique passwords that comply with organizational policies
- Limit knowledge of root credentials to essential personnel only
- Enable multi-factor authentication where possible
Conclusion
Knowing how to reset VMware vCenter root password after expiration is an essential skill for any VMware administrator. While password expiration serves important security purposes, being locked out of your vCenter appliance can cause significant operational disruptions.
The GRUB boot method provides the most reliable approach across VCSA versions 6.7, 7.0, and 8.0. By following the step-by-step instructions outlined in this guide and implementing proactive password management strategies, you can minimize downtime and maintain secure access to your virtual infrastructure.
Remember that prevention is always better than cure. Configure expiration notifications, document procedures thoroughly, and maintain regular password rotation schedules to avoid emergency reset situations.
